LAN9221-ABZJ
| Manufacturer | |
| Description | Ethernet CTLR Single Chip 10Mbps/100Mbps 1.8V/2.5V/3.3V 56-Pin QFN EP 10Based-T Ethernet Controller IC ETHERNET CTRLR 16BIT 56-QFN Ethernet controller; 10/100Base-T; 16-bit BUS (HBI); QFN56 Ethernet ICs 16bit High 10/100 Ethernet Controller 10Based-T Ethernet Con. 56VQFN |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 260 | Product | Ethernet Controllers |
| Unit Pack | 260 | Standard Package | 260 |
| Factory Pack Quantity | 260 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Standards | IEEE 802.3|IEEE 802.3u | Automotive | NO |
| Rad Hardened | No | Leadfree Defin | RoHS-conform |
Electrical
| Ethernet | 10/100Base-T | RAM Size | 16 kB |
| Data Rate | 10 Mb/s, 100 Mb/s | Interface | MII |
| Voltage Rating | 1.62 | Current - Output | 85mA |
| Current - Supply | 99.2 mA, 137.3 mA | Voltage - Supply | 3.3V |
| Current Rating (Max) | 85mA | Voltage - Supply (Min) | 1.62 V |
| Common Mode Transient Immunity (Min) | Commercial | ||
Mechanical
| Width | 8 | Height | 0.95 mm |
| Length | 8 mm | Weight | 0.01 kg |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 56-VFQFN Exposed Pad | Package Cooled | QFN EP |
| Connector Usage | Parallel | Length - Overall | 8 |
| Package Quantity | QFN EP | Number of Positions | 56 |
| Shell Size - Insert | 0.95(Max) | Supplier Device Package | 56-QFN (8x8) |
Product Info
| Spg | 2600 | Type | ethernet controller |
| Features | MAC / PHY | Function | Controller |
| Protocol | Ethernet | Manufacturer | Microchip Technology |
| Communications | Full Duplex|Half Duplex | Number of Units | 1 |
| Network Technology | 10BASE-T|100BASE-TX | Other Specifications | Yes |
| Printed Circuit Board | 56 | Number of Transmitters/Receivers | 1 Transceiver |
Environmental
| Operating Temperature | 0°C ~ 70°C | ||
Documents & Media
PDF Document
