PIC16C54C-04/P
| Manufacturer | |
| Description | . PIC16C54C-04/P - PIC PIC® 16C Microcontroller IC 8-Bit 4MHz 768B (512 x 12) OTP 18-PDIP from Microchip Technology. from now! |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 25 |
| Other Names | PIC16C54C04P | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | Part Status | :16C54 |
| Rad Hardened | No | Leadfree Defin | RoHS-conform |
Electrical
| Input | 12 | Speed | 4 MHz |
| Timer | 1 x 8 bit | Memory | :6KB |
| RAM Size | 25 byte | Core Size | 8-Bit |
| Core Type | PIC | Frequency | 4 MHz |
| Interface | :(Not Available) | Clock Rate | 40 MHz |
| Comparator | 0 | Memory Size | 25 B |
| Memory Type | OTP | Number of I/O | 12 |
| Voltage Range | 2-5.5V | Number of Bits | :8 |
| Voltage Rating | 2.5 → 5.5 V | Watchdog Timer | 1 |
| Clock Frequency | :4MHz | Frequency - Max | 4MHz |
| Oscillator Type | External | Voltage - Supply | 5 V |
| Number of Channels | 0 | Analog Input:Output | 0 |
| Non-Volatile Memory | 0Bytes | Program Memory Size | 512 byte |
| Program Memory Type | EPROM | Voltage - Input (Min) | 3V |
| Number of 8-bit Timers | 1 | Voltage - Supply (Min) | 4.5 V |
| Frequency (Center/Band) | 8bit | Power Dissipation (Max) | 800 mW |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | ||
Mechanical
| Width | 6.6mm | Height | 3.68mm |
| Length | 22.99mm | Weight | 0.000001 |
| Packaging | Tube | Termination | :Through Hole |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Number of Pins | :18 | Package / Case | 18PDIP |
| Package Cooled | PDIP | Material Finish | :- |
| Package Quantity | 425 | Size / Dimension | 22.99 x 6.6 x 3.68mm |
| Number of Positions | 18 | Supplier Device Package | 18-PDIP |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| Spg | 425 | USB | 0 |
| Type | PIC microcontroller | Series | PIC16 |
| Matchcode | PIC16C54C-04/P | Flash Size | :768Byte |
| On-Chip RAM | No | Peripherals | POR, WDT |
| Architecture | RISC | Programmable | Yes |
| Core Processor | PIC | Number of Units | 1 |
| Number of Timers | 1 | Controller Series | :PIC16C |
| Standard Leadtime | 14 weeks | RF Family/Standard | PIC16 |
| Microcontroller Features | :512b OTP PROM | ||
Environmental
| Temperature Range | :Commercial | Temperature - Test | 0°C |
| Operating Temperature | 0 to 70 °C | Operating Temperature - Junction | 70C |
