PIC12F1840-I/P
| Manufacturer | |
| Description | . PIC12F1840-I/P - PIC PIC® XLP™ 12F Microcontroller IC 8-Bit 32MHz 7KB (4K x 14) FLASH 8-PDIP from Microchip Technology. from now! |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | PIC12F1840IP | Standard Package | Rail / Tube |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| Tariff No | 85423190 | Rad Hardened | No |
Electrical
| Speed | 32 MHz | Timer | 2 x 8 bit |
| Memory | 7kB | RAM Size | 256 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Frequency | 32 MHz | Interface | I2C/SPI/USART |
| EEPROM Size | 256 x 8 | Memory Size | :256Byte |
| Number of I/O | 5 | Voltage Rating | 2.3 → 5.5 V |
| Watchdog Timer | 1 | Clock Frequency | :32MHz |
| Data Converters | A/D 4x10b, D/A 1x5b | Frequency - Max | 32MHz |
| Number of DAC's | 1 | Oscillator Type | Internal |
| Voltage - Supply | 3.3|5 V | Resolution (Bits) | 10bit |
| Number of Channels | 0 | Program Memory Size | 7 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 4 |
| Number of 8-bit Timers | 2 | Voltage - Supply (Min) | 2.5 V |
| Frequency (Center/Band) | 8bit | Power Dissipation (Max) | 800 mW |
| Voltage - Supply (Vcc/Vdd) | 2.3 V ~ 5.5 V | ||
Mechanical
| Width | 0.28in | Height | 0.2in |
| Length | 0.4in | Weight | 0.000833 |
| Packaging | Tube | Mounting Type | Through Hole |
| Number of Pins | :8 | Package / Case | 8PDIP |
| Package Cooled | PDIP | Material Finish | :- |
| Package Quantity | 60 | Size / Dimension | 0.4 x 0.28 x 0.2in |
| Number of Positions | 8 | Supplier Device Package | 18-PDIP |
| Number of Cores/Bus Width | 8 Bit | Pulse Width Distortion (Max) | 1(1 Channel) |
Product Info
| Spg | 60 | Type | PIC microcontroller |
| Features | XLP mode | On-Chip RAM | 4-chx10-bit |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Architecture | RISC |
| Connectivity | I²C, LIN, SPI, UART/USART | Programmable | Yes |
| Core Processor | PIC | Built in Switch | 32MHz, 32kHz |
| Number of Units | 1 | Number of Timers | 3 |
| Controller Series | :PIC12F18xx | RF Family/Standard | PIC12 |
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
