8125SDCBE
| Manufacturer | |
| Description | Switch Push Button ON Mom SPDT Round Plunger 20VAC 20VDC 0.4VA Momentary Contact PC Pins Panel Mount/Through Hole Pushbutton SWITCH PUSH SPDT 0.4VA 20V Pushbutton Switches SPDT ON-(ON) PCB AU Switch,Pushbutton,SNAPACTING,SPDT,PCTHRU-HOLE,GOLDCONTACTS |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 50 | Lead Time | 42 Days |
| Unit Pack | 1 | Subcategory | Switch Push Button |
| Product Category | Pushbutton Switches | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Standards | ULRecognized,CSACertified | Material Flammability Rating | UL 94 V-0 |
Electrical
| Circuit | SPDT | Operation | On-(On) |
| Power - Rated | 0.4@20VAC 20VDC VA | Voltage Rating | 20 V |
| Number of Poles | 1 | Switch Function | On-Mom |
| Contact Resistance | 50Milliohms(Max.) | Dielectric Strength | 1000V |
| Current Rating (Max) | 0.4VA (AC/DC) | Insulation Resistance | 10^9Ohms(Min.) |
| Voltage - Input (Min) | 20 | Switch Function/Rating | ON Mom |
Mechanical
| Depth | 6.86 | Height | 25.27 |
| Packaging | Bulk | Termination | PCBPins |
| Contact Form | SPDT | Actuator Type | Round, Plunger |
| Mounting Type | Panel Mount/Through Hole | Terminal Type | PC Pins |
| Contact Finish | Gold/Nickel | Mounting Style | Through Hole |
| Contact Material | Copper Alloy | Housing Material | Stainless Steel |
| Length - Overall | 12.7 | Actuator Material | (Glass/Nylon)|(Glass/Polyester) |
| Termination Style | PC Pin | Actuator Style/Size | Round Plunger |
| Number of Positions | 2 | Color - Actuator/Cap | White |
| Mounting Hole Diameter | 0.25" | Switch Actuation Level | SPDT |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | Material - Housing & Prism | N/A/Stainless Steel |
Product Info
| Type | Standard | Series | 8020 |
| Features | Tactile Feedback | Function | Momentary Contact |
| Electrical Life | 60,000 Cycles | Industry Aliases | 8125SDCBE |
Environmental
| Seal Rating | Epoxy | Operational Life | 60000Make-and-BreakCycles@FullLoad |
| Operating Temperature | -30 to 75 °C | ||
