SMLJ28A-TP
| Manufacturer | |
| Description | TVS Diodes - Transient Voltage Suppressors 45.4V 3000W 66A Diode TVS Single Uni-Dir 28V 3KW 2-Pin SMC T/R TVS DIODE 28VWM 45.4VC SMC |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | SMLJ28A-TPMSCT | Standard Package | 3,000 |
| Factory Pack Quantity | 3000 | Standard Package Name | DO-214-AB |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ESD Protection | No |
Electrical
| Channels | 1 Channel | Current - Surge | 66 A |
| Current - Output | 1 | Voltage - Supply | 28V |
| Current - Leakage | 0.005 uA | Number of Elements | 1 |
| Power - Peak Pulse | 3000W (3kW) | Voltage - Clamping | 45.4V |
| Current - Trip (It) | 1 mA | Voltage - Breakdown | 31.1V |
| Power Line Protection | No | Voltage - Input (Min) | 28 |
| Power - Average Forward | 3 kW | Unidirectional Channels | 1 |
| Current - Peak Pulse (8/20us) | 66 A | Current - Reverse Leakage @ Vr | 5 |
| Current - Peak Pulse (10/1000us) | 66A | Voltage - Reverse Standoff (Typ) | 28 V |
Mechanical
| Width | 6.22(Max) | Height | 2.62 mm |
| Length | 7.11 mm | Packaging | Tape and Reel |
| Lead Style | J-Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | DO-214AB, SMC |
| Package Cooled | DO-214AB | Length - Overall | 7.11(Max) |
| Package Quantity | SMC | Size / Dimension | 8.13 mm W x 7.11 mm L x 2.62 mm H |
| Termination Style | SMD/SMT | Number of Positions | 2 |
| Shell Size - Insert | 2.62(Max) | Supplier Device Package | DO-214AB, (SMC) |
Product Info
| Type | Zener | Series | SMLJ28 |
| Polarity | Unidirectional | Applications | General Purpose |
| Manufacturer | Micro Commercial Components (MCC) | Port Direction | Uni-Directional |
| Printed Circuit Board | 2 | ||
Environmental
| Operating Temperature | -55°C ~ 175°C | Operating Temperature - Junction | -55 to 175 |
