SM05-TP
| Manufacturer | |
| Description | ESD Suppressors 5V 300W ESD Suppressor TVS ±15KV 3-Pin SOT-23 T/R TVS DIODE 5VWM 9.8VC SOT23 ESD Suppressors / TVS Diodes 5V 300W |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | SM05-TPMSCT | Product Category | ESD Suppressors |
| Standard Package | 3,000 | Factory Pack Quantity | 3000 |
| Standard Package Name | SOT-23 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| ESD Protection | ±15@Air Gap/±8@Contact Disc | ||
Electrical
| Capacitance | 110 pF | Voltage Rating | 5 |
| Voltage - Supply | 5V (Max) | Number of Channels | 2 Channel |
| Number of Elements | 2 | Power - Peak Pulse | 300W |
| Voltage - Clamping | 9.8V | Capacitance @ Vr, F | 110 pF |
| Voltage - Breakdown | 7.3 V | Power Line Protection | No |
| Capacitance @ Frequency | 110pF @ 1MHz | Power - Average Forward | 225 mW |
| Power Dissipation (Max) | 225 mW | Unidirectional Channels | 2 |
| Current - Peak Pulse (8/20us) | 12 A | Current - Reverse Leakage @ Vr | 10 |
| Current - Peak Pulse (10/1000us) | 1A (8/20µs) | ||
Mechanical
| Packaging | Reel | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Package / Case | SOT-23 |
| Package Quantity | SOT-23 | Termination Style | SMD/SMT |
| Number of Positions | 3 | Supplier Device Package | SOT-23 |
Product Info
| Type | TVS | Series | SM05 |
| Polarity | Unidirectional | Applications | General Purpose |
| Manufacturer | Micro Commercial Components (MCC) | Configuration | Dual Common Anode |
| Port Direction | Uni-Directional | ||
Environmental
| Operating Temperature | -55°C ~ 150°C | ||
Documents & Media
PDF Document
