ESD5V0D5-TP
| Manufacturer | |
| Description | ESD Suppressors 5V 174W ESD Suppressor TVS ±30KV 2-Pin SOD-523 T/R TVS DIODE 5VWM 11.6VC SOD523 ESD Suppressors / TVS Diodes 5V 174W |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ESD5V0D5-TPMSCT | Product Category | ESD Suppressors |
| Standard Package | 8,000 | Factory Pack Quantity | 3000 |
| Standard Package Name | SOD-523 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| ESD Protection | ±30@Air Gap/±30@Contact Disc/16@H... | ||
Electrical
| Capacitance | 80 pF | Voltage Rating | 5 |
| Voltage - Supply | 5V | Number of Channels | 1 Channel |
| Number of Elements | 1 | Power - Peak Pulse | 174W |
| Voltage - Clamping | 11.6V | Capacitance @ Vr, F | 80 pF |
| Voltage - Breakdown | 6.2 V | Power Line Protection | No |
| Capacitance @ Frequency | 80pF @ 1MHz | Power - Average Forward | 200 mW |
| Power Dissipation (Max) | 200 mW | Unidirectional Channels | 1 |
| Current - Peak Pulse (8/20us) | 5 A | Current - Reverse Leakage @ Vr | 0.08 |
Mechanical
| Packaging | Reel | Lead Style | Flat |
| Mounting Type | Surface Mount | Package / Case | SOD-523 |
| Package Quantity | SOD-523 | Termination Style | SMD/SMT |
| Number of Positions | 2 | Supplier Device Package | SOD-523 |
Product Info
| Type | TVS | Series | ESD5V |
| Polarity | Unidirectional | Applications | General Purpose |
| Manufacturer | Micro Commercial Components (MCC) | Configuration | Single |
| Port Direction | Uni-Directional | ||
Environmental
| Operating Temperature | -55°C ~ 150°C | ||
