SP-480-24
| Manufacturer | |
| Description | Linear and Switching Power Supplies 24V 22A 480W Active PFC Function AC/DC Power Supply Single-OUT 24V 22A 480W 9-Pin Power Supply; AC-DC; 24V@20A; 165-264V In; Enclosed; Panel Mount; PFC; SP Series Pwr sup.unit: pulse; 480W; 24VDC; 20A; 85÷264VAC; 120÷370VDC; 1.7kg SP-480-24 from Mean Well, 480 Watt, Single Output Switched-mode power supply 1 output, SP-480-24, Mean Well |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Product Category | Linear and Switching Power Supplies |
Compliance
| RoHS | RoHS Compliant | Protection | overload, voltage growth, short-circuit |
Electrical
| Output | 24VDC@20A | Frequency | 47...63 Hz |
| Operation | PFC | Efficiency | 87.00% |
| Power - Max | 480 Watts | Output Power | 480 W |
| Power - Rated | 480W | Power - Output | 480 W |
| Voltage Rating | 88 VAC to 230 VAC, 124 VDC to 370 VDC | Current - Output | 20A |
| Voltage - Supply | 120...370V DC, 85...264V AC | Number of Outputs | 1 |
| Power Supply Type | modular | AC Voltage - Input | 85...264 VAC |
| Current - Output 1 | 20.0 A | Voltage - Input (Min) | 24 VDC |
| Voltage - Supply, Battery | 120...370 VDC | Current - Output / Channel | 20 A |
Mechanical
| Size | 278 x 127 x 43 mm | Width | 127 mm |
| Height | 43 mm | Length | 278 mm |
| Weight | 1.7kg | Size - Body | 278 x 127 x 43mm |
| Mounting Type | Panel | Mounting Style | Chassis |
| Panel Mount Type | Enclosed | Primary Material | AC-DC |
| Size / Dimension | 278 mm L x 127 mm W | ||
Product Info
| Type | Commercial | Series | MEAN WELLSP-480 |
| Features | 3-Years Warranty, Remote On, Off, Remote Sense, Low Profile, Short Circuit Protections, Overload Protections, Over Voltage Protections, Over Temperature Protections | Application | Commercial |
| Manufacturer | SP Series | Stock Status | 3 |
| Configuration | Enclosed | Electrical Life | terminal block |
| Number of Units | 1 | ||
Environmental
| Operating Temperature | -20...60°C | ||
