LPF-60-48
| Manufacturer | |
| Description | LED Drivers Power Supplies 60W 48V 1.25A LED PS W/PFC AC/DC Power Supply Single-OUT 48V 1.25A 60W 4-Pin Power Supply; AC-DC; 48V@1.25A; 100-305V In; Enclosed; LED Driver; PFC; LPF Series Pwr sup.unit: pulse; for LED diodes; 60W; 48VDC; 1.25A; 90÷305VAC LPF-60-48 from Mean Well, 60 Watt, Single Output LED driver, LPF-60-48, Mean Well Mean Well LED 驱动器 , 48V, 1.25A, 60W |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Product Category | LED Drivers Power Supplies |
Compliance
| RoHS | RoHS Compliant | Protection | overload, overheating, voltage growth, short-circuit |
Electrical
| Input | 90-305 VAC | Output | 48VDC@1.25A |
| Frequency | 47...63 Hz | Operation | PFC |
| Efficiency | 90.00% | Power - Max | 60W |
| Output Power | 60 W | Power (Watts) | 60 W |
| Power - Rated | 60W | Operating Mode | Constant Current (CC) |
| Power - Output | 60 W | Voltage Rating | 90 VAC to 305 VAC, 127 VDC to 431 VDC |
| Current - Output | 1.25A | Voltage - Supply | 90...305V AC, 127...431V DC |
| Number of Outputs | 1 | Power Supply Type | pulse |
| Current - Output 1 | 1.25 A | Current Rating (Max) | 1.25A |
| Voltage - Input (Min) | 48 VDC | Power Factor Correction | PFC |
| Current Regulation - Line | CV + CC | Current - Output / Channel | 1.25 A |
| Voltage - Protection Level (VP) (2416) | IP 67 | ||
Mechanical
| Size | 162.5 x 43.5 x 32 mm | Depth | 43.5 |
| Width | 162.5 | Height | 32 |
| Weight | 0.45kg | Size - Body | 43 x 162.5 x 32mm |
| Mounting Type | Panel | Mounting Style | Chassis |
| Package Quantity | PLASTIC6.39 x 1.69 x 1.26" | Panel Mount Type | Enclosed |
| Primary Material | AC-DC | Size / Dimension | 162.5 mm L x 42.5 mm W x 32 mm H |
| Termination Style | Stranded Wires, 60 cm, 2 x AWG18 | Color - Connectors | white |
Product Info
| Type | LED Driver | Series | MEAN WELLLPF-60 |
| Features | 3-Years Warranty, Short Circuit Protections, Over Current Protections, Over Voltage Protections, Over Temperature Protections | Function | power factor correction function |
| Application | Commercial | Manufacturer | LPF Series |
| Stock Status | 5 | Configuration | Enclosed |
| Electrical Life | 300mm wires | Number of Units | 1 |
| Application Specifics | for LED diodes | ||
Environmental
| Ingress Protection | IP67 | Operating Temperature | -40...70°C |
