BCAP2000 P270 K05
| Manufacturer | |
| Description | Supercapacitors / Ultracapacitors 2.7V 2000F Weldable post CAP SUPER 2000F 2.7V SOLDER POST |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Supercapacitors | Part # Aliases | 108325B |
| Product Category | Supercapacitors / Ultracapacitors | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Tolerance | 20 % | Capacitance | 2000 Farads |
| Power - Rated | 6900 W / kg | Voltage Rating | 2.7 V |
| Current - Leakage | 4.2 mA | Current Rating (Max) | 123 A |
| ESR (Equivalent Series Resistance) | 0.35 mOhms | ||
Mechanical
| Diameter | 60.7 mm | Pin Diameter | 14 mm |
| Package / Case | 102 mm | Size / Dimension | 60.7 mm Dia. x 102 mm L |
| Termination Style | Radial | ||
Product Info
| Series | K2 | ||
Environmental
| Operating Temperature | - 40 C to + 65 C | ||
