LDS-HTC512RI
| Manufacturer | |
| Description | LED Displays & Accessories .56 7-seg,c/c H-Tmp 565nm Grn Gry/Wh LED DISPLAY 7-SEG GREEN 1DIGT CC .56in.7-segdspl,c/chightemp,565nmgreen,gray/white |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 67-2110-5 | Product Category | LED Displays & Accessories |
| Standard Package | 40 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Wavelength | 565 nm | Display Type | 7 Segment |
| Current - Output | 10mA | Voltage - Supply | 2.2V |
| Wavelength - Peak | 565nm | Millicandela Rating | 3.5mcd |
| Power Dissipation (Max) | 105mW | Current - Peak Pulse (10/1000us) | 25mA(perSegment) |
Mechanical
| Color | Green | LED Color | Green |
| Packaging | Tube | Common Pin | Common Cathode |
| Mounting Style | ThurHole | Package / Case | 10-DIP (0.600", 15.24mm) |
| Overall Diameter | 19.00×12.60mm | Size / Dimension | 0.748" H x 0.496" W x 0.315" D (19.00mm x 12.60mm x 8.00mm) |
| Illumination Color | Green | ||
Product Info
| Viewing Area | —mm | Character Size | 0.56 in |
| Digit/Alpha Size | 0.56" (14.20mm) | Channels per Circuit | 1 |
| Digits or Characters | 1 | Number of Characters | 1 |
| Application Specifics | LED | ||
Environmental
| Mechanical Life | New Technology: Cutting edge technology for the newest designs. | Operating Temperature | + 85 C |
| Luminous Flux @ Current/Temperature | 3500 mcd | ||
