SMCJ30CA
| Manufacturer | |
| Description | TVS Diodes - Transient Voltage Suppressors 30Vr 1500W 31A 5% BiDirectional Diode TVS Single Bi-Dir 30V 1.5KW 2-Pin DO-214AB T/R TRANSIL BI 1,5KW 36V SMC TVS DIODE 30VWM 48.4VC SMC TVS Diode Bi-Directional SMCJ30CA 48.4V, 1500W, DO-214AB 2-Pin DIODE, TVS, 30V, 1.5KW, BI, 5%, SMC Diode: transil; 1.5kW; 30V; 31A; bidirectional; DO214AB Littelfuse 双向 TVS 二极管, 1500W, 48.4V, 2针 DO-214AB封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 3000 | Unit Pack | 3000 |
| Other Names | SMCJ30CALFTR | Product Category | TVS Diodes - Transient Voltage Suppressors |
| Standard Package | 3,000 | Factory Pack Quantity | 3000 |
| Standard Package Name | DO-214-AB | ||
Compliance
| RoHS | Lead free by exemption / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Automotive | NO | ESD Protection | No |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Channels | 1 Channel | Tolerance | 5% |
| TVS Polarity | :Bidirectional | Power - Rated | 1.5kW |
| Current - Surge | 31 A | Current - Output | 1 |
| Voltage - Supply | 30V | Current - Leakage | 1µA |
| Number of Elements | 1 | Power - Peak Pulse | 1500W (1.5kW) |
| Voltage - Clamping | 48.4V | Diode Configuration | :DO-214AB |
| Voltage - Breakdown | 36V | Contact Voltage (Max) | 30V |
| Power Line Protection | No | Voltage - Input (Min) | 30 |
| Bidirectional Channels | 1 | Voltage - Supply (Min) | 30 V |
| Power Dissipation (Max) | 1.5kW | Current - Peak Pulse (8/20us) | :31A |
| Current - Reverse Leakage @ Vr | 1 | Current - Peak Pulse (10/1000us) | 31A |
Mechanical
| Width | 6.22(Max) | Weight | 0.00021 |
| Packaging | Tape and Reel | Lead Style | J-Lead |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | SMC | Length - Overall | 7.11(Max) |
| Package Quantity | DO-214AB | Size / Dimension | 6.22 mm W x 8.13 mm L x 2.62 mm H |
| Termination Style | SMD/SMT | Number of Positions | 2 |
| Shell Size - Insert | 2.42(Max) | Supplier Device Package | SMC |
Product Info
| Spg | 3000 | Type | Zener |
| Series | SMCJ | Polarity | Bidirectional |
| Matchcode | SMCJ30CA (BFK) | Structure | bidirectional |
| Diode Type | transil | Applications | Telecom |
| Port Direction | Bi-Directional | Number of Units | 1 |
| Standard Leadtime | 12 weeks | Application Specifics | BIDIRECTIO |
| Printed Circuit Board | 2 | ||
Environmental
| Operating Temperature | -55°C ~ 150°C | Operating Temperature - Junction | -65 to 150 |
