35414000029
| Category |
对参数有疑问?问 AI 助手
Business
| Product | Specialty Fuses | Product Category | Fuses |
| Standard Package | 100 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | Rad Hardened | No |
| Approval Agency | cULus | ||
Electrical
| Indicator | Without Indicator | Melting I2t | 43 |
| Power - Rated | 3.2 W | Response Time | Fast |
| Characteristic | fast-blow | Voltage Rating | 440 V |
| Interrupt Output | 1 kA at 440 VAC | Voltage - Rated AC | 440 V |
| Current Rating (Max) | 4 A | Voltage - Supply (Min) | 1000A |
Mechanical
| Depth | Not Required mm | Height | Not Required mm |
| Length | 32 | Diameter | 6.3 mm |
| Packaging | Bulk | Body Material | Ceramic |
| Mounting Type | Holder | Mounting Style | Holder |
| Package / Case | 32 mm | Housing Material | Ceramic |
| Length - Overall | 32 mm | Size / Dimension | 32 mm L x 6.3 mm D |
| Termination Style | Clip | Number of Positions | 2 |
| Supplier Device Package | Cartridge Fuses | Diameter - Outside, Non-Expanded | 6.3 x 32 mm |
Product Info
| Form | Ceramic tube | Type | Ceramic Fuse |
| Series | 354 | Fuse Size | 3AB (6.3 mm x 32 mm) |
| Fuse Type | Fast Blow | Product Type | Ceramic Fuse |
Environmental
| Must Operate | Fast | Operating Temperature | - 25 C to + 70 C |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 354_LF_011906.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
