点击放大查看
SDA04H0SB
| Manufacturer | |
| Description | Switch DIP OFF ON SPST 4 Recessed Slide 0.1A 24VDC Gull Wing 1000Cycle 2.54mm SMD Tube Switch DIP OFF ON SPST 4 Recessed Slide 0.1A 24VDC Gull Wing 1000Cycles 2.54mm SMD Tube DIP 4P SMT TOP ACT.FLUSH Tape SWITCH DIP TAPE SEALED 4POS 24V DIP Switches / SIP Switches FLUSH ACT 4 POS |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 35 | Unit Pack | 35 |
| Product Category | DIP Switches / SIP Switches | Standard Package | Rail / Tube |
| Factory Pack Quantity | 35 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Rad Hardened | No |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Circuit | SPST | Voltage Rating | 24 V |
| Switch Function | OFF ON | Voltage - Supply | 24 DCV |
| Current Rating (Max) | 0.1@5VDC A | Switch Function/Rating | OFF ON |
| Contact Rating @ Voltage | 0.025A @ 24VDC | Voltage - DC Reverse (Vr) (Max) | 50V |
| Current - Peak Pulse (10/1000us) | 25mA | ||
Mechanical
| Seal | Tape(Polyamide) | Depth | 9.3 mm |
| Pitch | 2.5mm | Width | 7.5mm |
| Height | 3.5mm | Length | 12.1mm |
| Packaging | Tube | Orientation | Top Actuated |
| Termination | SMT | Contact Form | SPST |
| Pitch - Post | 2.54 mm | Actuator Type | FLUSH |
| Mounting Type | Surface Mount | Terminal Type | Gull Wing |
| Actuator Level | Flush | Connector Type | NOY/N |
| Contact Finish | Gold | Mounting Style | Surface Mount |
| Package / Case | DIP | Contact Material | Beryllium Copper |
| Length - Overall | 12.1 mm | Termination Style | SMD/SMT |
| Actuator Style/Size | Recessed Slide | Number of Positions | 4 |
| Switch Actuation Level | SPST | ||
Product Info
| Series | SDA | Washable | Yes |
| Matchcode | SDA04H0SB ** | Switch Type | DIP |
| Tape Included | YesY/N | Electrical Life | 1000cycles |
| Standard Leadtime | 6 weeks | Number of Positions (Convert From) | 4 |
Environmental
| Mechanical Life | 1000 | Ingress Protection | No |
| Operating Temperature | -40 to 85 °C | ||
