LTL-1BEHJ
| Manufacturer | |
| Description | LED Bi-Color Green/Red Orange 565nm/630nm 3-Pin Standard LEDs - Through Hole Red Orange/Green 621/569nm, 19/19mcd LED CBI 3MM RED-ORN/GREEN DIFF LED Bi-Color Green/Orange Red 565nm/630nm 3-Pin 3MM RED/ORANGE GREEN DIFFUSED |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Standard LEDs - Through Hole | Standard Package | Bulk |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Leadfree Defin | RoHS-conform |
Electrical
| Current | 30mA Green, 30mA Red | Optic Size | T-1 |
| Lamp Output | No | Luminous Flux | 19 mcd |
| Sensing Angle | 75 ° | Viewing Angle | 75 ° |
| Current - Bias | 20 mA | Voltage Rating | 2.1V Green, 2.1V Red |
| Voltage - Supply | 2 V | Wavelength - Peak | 565/630 nm |
| Number of Elements | 1 | LED Forward Current | 20 mA |
| LED Forward Voltage | 2 V, 2.1 V | Millicandela Rating | 19mcd Green, 19mcd Red |
| Current Rating (Max) | 30mA Green, 30mA Red | Wavelength - Dominant | 573/625 nm |
| Power Dissipation (Max) | 100 | Frequency - Self Resonant | 625/573 nm |
| Current - Peak Pulse (10/1000us) | 30 | MSCP (Mean Spherical Candle Power) | 19mcd Green, 19mcd Red |
| Voltage - Gate Trigger (Vgt) (Max) | 5 | ||
Mechanical
| Color | Green/Red Orange | Height | 3.0 mm |
| Packaging | Bulk | Lens Color | Diffused |
| Lens Style | Circular | Lens Diameter | 3x3x4.15 |
| Mounting Type | Through Hole | Mounting Style | Top Mount |
| Package / Case | 3 MM | Lens Style/Size | Round with Domed Top, 3mm |
| Insulation Color | DIFFUSED | Diameter - Outside | 4.05 |
| Illumination Color | Orange, Green | Number of Positions | 3 |
| Shell Size - Insert | 5.15 | ||
Product Info
| Type | Bi-Color | Lens Type | Colorless Diffused |
| Configuration | Single | Number of LEDs | 2 |
| Channels per IC | Single | Output Configuration | Through Hole |
| Printed Circuit Board | 3 | ||
Environmental
| Operating Temperature | 100 | Luminous Flux @ Current/Temperature | 19 mcd, 19 mcd |
