CONMMCX007-R178
| Manufacturer | |
| Description | RF コネクタ MMCX Male Cable End Crimp - RG-178 Cable CONN MMCX PLUG STR 50 OHM SOLDER RF Connectors / Coaxial Connectors MMCX Male Cable End Crimp - RG-178 Cable |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Connectors | Product Category | RF Connectors / Coaxial Connectors |
| Standard Package | 100 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Impedance | 50 Ohm | Voltage Rating | 170V |
| Frequency - Max | 6GHz | ||
Mechanical
| Packaging | Bulk | Cable Type | RG-178 |
| Body Finish | Gold | Cable Group | RG-178 |
| Orientation | Straight | Body Material | Brass |
| Housing Color | Gold | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Male Pin | Contact Finish | Gold |
| Fastening Type | Snap-On | Connector Style | MMCX |
| Contact Material | Beryllium Copper | Termination Style | Crimp |
| Shield Termination | Crimp | Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | ||
Product Info
| Gender | Plug | Features | Heat Shrink Tubing |
| RF Family/Standard | MMCX | ||
Environmental
| Operating Temperature | -65°C ~ 165°C | ||
