BL-33F0-0142
| Manufacturer | |
| Description | LED Lighting Modules RGB 3000 Series LED ARRAY RD/GN/BL 1.25X1.05"SMD |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | LED Light Engines | Tradename | Lamina |
| Other Names | 521-1013 | Product Category | LED Lighting Modules |
| Standard Package | 24 | Factory Pack Quantity | 20 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage | * | Wavelength | 624nm, 525nm, 470nm |
| Luminous Flux | 114 lm, 145 lm, 47 lm | Power - Rated | 5.6 W, 8.4 W, 8.4 W |
| Driver Circuitry | No | LED Forward Current | 1.17 A |
| LED Forward Voltage | 4.8 V, 7.2 V, 7.2 V | Wavelength - Dominant | 629 nm, 535 nm, 475 nm |
Mechanical
| Size | 31.75 mm x 26.67 mm x 2.29 mm | Color | Red, Green, Blue (RGB) |
| Width | 26.67 mm | Height | 2.29 mm |
| Length | 31.75 mm | Packaging | Tray |
| Connector Usage | No | Illumination Color | RGB |
Product Info
| Configuration | Rectangle | Number of LEDs | 39 |
Environmental
| Mechanical Life | Obsolete | Luminous Flux @ Current/Temperature | 114 lm Red, 145 lm Green, 47 lm Blue |
Documents & Media
PDF Document
