ERA.1S.306.CLL
| Manufacturer | |
| Description | Circular Push Pull Connectors SIZE 1 6-PIN SOLDER FEMALE PANL RECEPT CONN PNL MNT RCPT 6SKT SLD CUP Device socket, S-series 6-pin Poles=6, ERA.1S.306.CLL, Lemo |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 98 Days | Subcategory | Not Specified |
| Product Category | Circular Push Pull Connectors | Standard Package | 50 |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Number of Poles | 6 | Current Rating (Max) | 7A |
| Current Rating - Appliance Inlet | 6 | Voltage - Protection Level (VP) (2416) | IP 50 |
Mechanical
| Packaging | Bulk | Orientation | Keyed |
| Shell Style | Receptacle | Termination | Solder Cup |
| Weight (g): | 8.80000 | Mounting Type | Panel Mount, Bulkhead - Rear Side Nut |
| Shell Plating | Chrome Plated | Connector Type | Receptacle, Female Sockets and Male Pins |
| Contact Finish | Gold | Fastening Type | Push-Pull |
| Locking Feature | Push-Pull | Contact Material | CuNi+Au |
| Housing Material | Brass (CuZn) | Termination Style | Solder |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 6 |
| Number of Positions | 6 | Shell Size - Insert | 306 |
| 1st Connector Gender | Female | Shell Material, Finish | Brass, Chrome Plated |
Product Info
| Design | Panel-mount female receptacle | Series | S |
| Features | Shielded | Main Purpose | Shielded |
| Product Type | Connectors | Connection Method | 0.34 |
| Output Configuration | Panel Mount, Bulkhead - Rear Side Nut | ||
Environmental
| Ingress Protection | IP50 - Dust Protected | Operating Temperature | -55°C ~ 250°C |
