LA 150-P
| Manufacturer | |
| Description | SENSOR CURR 150A -/+15V TH LEM 电流传感器, 最大为 150A, 75mA output current |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Output | Ratiometric, Voltage | Accuracy | ±0.5% |
| Frequency | DC ~ 150kHz | Linearity | ±1% |
| Sensor Type | Closed Loop Hall Effect | Response Time | 0.5µs |
| Frequency Range | 150 kHz | Current - Output | 16mA |
| Current - Supply | 10mA | Voltage - Supply | -15 V ~ 15 V |
| Current - Sensing | 150A | Number of Channels | 1 |
| Current Rating (Max) | 75mA | ||
Mechanical
| Width | 37mm | Packaging | Bulk |
| Polarization | Bidirectional | Mounting Type | Through Hole |
| Package / Case | Module, Single Pass Through | Length - Overall | 16mm |
| Transformer Type | 闭路霍尔效应 | Height - Seated (Max) | 33mm |
| Outside Cable Diameter (Max) | 13.5 x 10mm | ||
Product Info
| For Measuring | AC/DC | ||
Environmental
| Operating Temperature | -10°C ~ 80°C | ||
