CM0805C161R-10
| Manufacturer | |
| Description | Ind Common Mode Choke 160Ohm 100MHz 300mA 0805 T/R CHOKE COMMON MODE 160 OHMS SMD EMI Filter Beads, Chips & Arrays 160ohms 100MHz .3A 0805 SMD CHOKE, COMMON, 100MHZ, SMD, 160R |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Ferrite Chip Beads, Common Mode | Lead Time | 84 Days |
| Other Names | 240-2569-1 | Subcategory | Common Mode Chokes |
| Product Category | EMI Filter Beads, Chips & Arrays | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85049011 | ||
Electrical
| Current | 300mA | Impedance | 160 Ohm |
| Filter Type | Data, Signal Line | Range deg/s | :LAIRD TECHNOLOGIES - 05 Series |
| Test Frequency | 100 MHz | DC Resistance (DCR) | 350 mOhm Max |
| Current Rating (Max) | 300 mA | DC Resistance (DCR) (Max) | :0.35ohm |
| Resistance - Initial (Ri) (Min) | 350 mOhm | ||
Mechanical
| Width | 1.2 mm | Height | 1.2 mm |
| Weight | 0.00001 | Packaging | Tape and Reel |
| Shielding | Unshielded | Height (Max) | 0.055" (1.40mm) |
| Mounting Type | Surface Mount | Connector Type | :SMD |
| Package / Case | 0805 | Size / Dimension | 0.079" L x 0.047" W (2.00mm x 1.20mm) |
| Termination Style | SMD/SMT | Shell Size - Insert | :0805 |
| Dimensions - Overall | :2mm x 1.2mm x 1.2mm | ||
Product Info
| Type | Common Mode Choke | Series | CM |
| Number of Lines | 2 | ||
Environmental
| Operating Temperature | - 40 C to + 125 C | ||
