28R1227-100
| Manufacturer | |
| Description | Ferrite Core Solid Core 31.12mm 13.3mm 8.2mm Ribbon and Flex Cables CABLE CORE RIBBON/FLEX 24.77MM Ferrite Cable Cores 128ohms 100MHz 24.77mm Inside Slot |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Flat Ribbon Cable Cores Solid | Lead Time | 84 Days |
| Subcategory | Ferrite Core | Product Category | Ferrite Cable Cores |
| Standard Package | Bulk | Factory Pack Quantity | 63 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Impedance | 128 Ohm | Test Frequency | 100MHz |
Mechanical
| Depth | 13.3 mm | Height | 8.2 mm |
| Length | 0.590" L (15.00mm) | Weight | 0.479840 oz |
| Material | 28 | Core Material | 28 |
| Mounting Type | Free Hanging | Inner Dimension | 0.975" W x 0.075" H (24.77mm x 1.91mm) |
| Length - Inside | 1.91 mm | Outer Dimension | 1.225" W x 0.325" H (31.12mm x 8.26mm) |
| Width - Overall | 13.3 mm | Length - Overall | 31.12 mm |
| Diameter - Outside, Non-Expanded | 8.26 mm | ||
Product Info
| Type | Solid Core | Design | Solid |
| Applications | Ribbon and Flex Cables | RF Family/Standard | 28R |
Environmental
| Operating Temperature | - 40 C to + 125 C | ||
