0918BD41B050E
| Manufacturer | |
| Description | BALUN DUAL BAND GSM/CDMA 918MHZ Signal Conditioning 1850-1920 MHz Balun Ceramic Chip |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Baluns | Other Names | 712-1018-1 |
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free by exemption / RoHS Compliant | ||
Electrical
| Frequency | 920 MHz, 1.885 GHz | Impedance | 50 Ohms |
| Insertion Loss | 1.2 dB, 1.7 dB | Frequency Range | 900MHz ~ 940MHz, 1.85GHz ~ 1.92GHz |
| Return Loss (Min) | 8.5dB | Insertion Loss (Max) | 1.2dB, 1.7dB |
| Impedance - Unbalanced/Balanced | 50 / 50 Ohm | ||
Mechanical
| Packaging | Cut Tape (CT) | Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) | Termination Style | SMD/SMT |
Product Info
| Type | Dual Band, Ceramic | ||
Environmental
| Operating Temperature | - 40 C to + 85 C | ||
Documents & Media
PDF Document
