PM2R013NQ1R500
| Manufacturer | |
| Description | 基板間およびメザニンコネクタ Slimline SATA CONN RCPT SATA R/A 13POS SMD Board to Board & Mezzanine Connectors Slimline SATA |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 670-2452-2 | Product Category | Board to Board & Mezzanine Connectors |
| Standard Package | 500 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Current Rating (Max) | 1.5 A | Insulation Resistance | 1000 MOhms |
Mechanical
| Pitch | 1.27 mm | Packaging | Tape & Reel (TR) |
| Termination | Solder | Mounting Type | Surface Mount, Right Angle |
| Connector Type | SATA | Contact Finish | Gold |
| Number of Rows | 1 | Connector Style | Receptacle |
| Contact Material | Copper Alloy | Housing Material | Liquid Crystal Polymer (LCP) |
| Termination Style | SMD | Number of Contacts | 13 |
| Number of Positions | 13 | Contact Finish Thickness | 12µin (0.30µm) |
Product Info
| Series | PM2 | Features | Board Lock, Flange |
| Product Type | Hermaphroditic Connectors | ||
Environmental
| Operating Temperature | - 40 C to + 85 C | ||
