TR1412RFH1NB
| Manufacturer | |
| Description | Conn Ringlock Circular SKT 12 POS Crimp ST Panel Mount 12 Terminal 1 Port SOCKET, PANEL, 12WAY CONN HSG RCPT WALL MNT 12POS SKT |
| Category |
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | :250V | Voltage - Working | :250VAC |
| Current - Max/Contact | :13A | Insulation Resistance | :5000Mohm |
Mechanical
| Weight | 0.0983 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Weight (g): | 10.00000 | Contact Type | Crimp, Solder and Solder Cup |
| Mounting Type | Panel Mount | Connector Type | :Circular Industrial |
| Fastening Type | Bayonet Lock | Insertion Angle | :14-12 |
| Locking Feature | :Copper Alloy | Material Finish | :- |
| 1st Contact Gender | :Socket | Number of Positions | :12 |
| Shell Size - Insert | :14 | Shell Material, Finish | Nylon |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Note | Contacts Not Provided | Type | Ringlock Circular |
| Gender | RCP | Series | :TRIDENT Ringlock |
| Measuring Range | :14 | ||
Environmental
| NEMA Frame Size | :IP65 | Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Operating Temperature | :105°C | ||
