KPT07E20-41PW
| Manufacturer | |
| Description | Conn MIL-C-26482 Circular PIN 41 POS Solder ST Jam Nut 41 Terminal 1 Port CONN RCPT 41POS W/PIN JAM NUT CONNECTOR, CIRCULAR, SIZE 20, 41WAY |
| Category |
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Approval Agency | :VG95328 |
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | W | Termination | Solder |
| Weight (g): | 71.64600 | Mounting Type | Jam Nut |
| Connector Type | Receptacle, Male Pins | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Package / Case | :Jam Nut Receptacle |
| Insertion Angle | :20-41 | Material - Body | :Aluminium |
| Contact Material | :Copper | 1st Contact Gender | :Pin |
| Number of Contacts | :41 | Contact Termination | :Solder |
| Number of Positions | 41 | Shell Size - Insert | 20-41 |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | Contact Finish Thickness | 50µin (1.27µm) |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Type | MIL-C-26482 Circular | Gender | RCP |
| Series | :KPT | ||
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
