点击放大查看
KPT06P14-15S
| Manufacturer | |
| Description | Conn MIL-C-26482 Circular SKT 15 POS Solder ST Cable Mount 15 Terminal 1 Port CONN PLUG 15POS CABLE SKT CIRCULAR, SIZE 14, 15 WAY SKT |
| Category |
Business
| Other Names | KPT06P1415S | Standard Package | Bulk |
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Approval Agency | :VG95328 |
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A, 13A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Solder |
| Weight (g): | 28.49000 | Mounting Type | Cable Mount |
| Connector Type | Plug, Female Sockets | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Insertion Angle | :14-15 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Socket | Number of Contacts | :15 |
| Contact Termination | :Solder | Number of Positions | 15 |
| Shell Size - Insert | 14-15 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 50µin (1.27µm) | 1st Connector Mounting Type | :Cable |
Product Info
| Type | MIL-C-26482 Circular | Gender | PL |
| Series | :KPT | ||
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
Documents & Media
