KPSE06P20-39S
| Manufacturer | |
| Description | Conn MIL-C-26482 Circular SKT 39 POS Crimp ST Cable Mount 39 Terminal 1 Port CONN PLUG 39POS CBL MNT W/SKTS CONNECTOR, CIRCULAR, SIZE 20, 39WAY |
| Category |
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Approval Agency | :MIL-C-26482 |
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A, 13A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Weight (g): | 54.86600 | Mounting Type | Cable Mount |
| Connector Type | Plug, Female Sockets | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Package / Case | :Straight Plug |
| Insertion Angle | :20-39 | Material - Body | :Aluminium |
| Contact Material | :Copper | 1st Contact Gender | :Socket |
| Number of Contacts | :39 | Contact Termination | :Crimp |
| Number of Positions | 39 | Shell Size - Insert | 20-39 |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | Contact Finish Thickness | 50µin (1.27µm) |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Type | MIL-C-26482 Circular | Gender | PL |
| Series | :KPSE | ||
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
