KPSE01J16-26P
| Manufacturer | |
| Description | Conn MIL-C-26482 Circular PIN 26 POS Crimp ST Cable Mount 26 Terminal 1 Port CONN RCPT 26POS CBL MNT W/PINS CIRCULAR, SIZE 16, 26 WAY SKT |
| Category |
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Approval Agency | :MIL-C-26482 |
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Weight (g): | 65.60000 | Mounting Type | Cable Mount |
| Connector Type | Receptacle, Male Pins | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Insertion Angle | :16-26 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Pin | Number of Contacts | :26 |
| Contact Termination | :Crimp | Number of Positions | 26 |
| Shell Size - Insert | 16-26 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 50µin (1.27µm) | 1st Connector Mounting Type | :Cable |
Product Info
| Type | MIL-C-26482 Circular | Gender | PL |
| Series | :KPSE | Features | Sealing Gland, Strain Relief |
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
Documents & Media
