KPSE00J14-12S

Manufacturer	ITT Inc.
Description	Conn MIL-C-26482 Circular SKT 12 POS Crimp ST Wall Mount 12 Terminal 1 Port CONN RCPT 12POS WALL MNT W/SKTS CIRCULAR, SIZE 14, 12 WAY SKT
Category	Connector SolutionsCircular ConnectorsStandard Circular Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Bulk

Compliance

RoHS	Contains lead / RoHS non-compliant	SVHC	:No SVHC (20-Jun-2013)
Tariff No	85369010	Approval Agency	:MIL-C-26482

Electrical

Voltage Rating

600VAC, 850VDC

Current Rating (Max)

7.5A, 13A

Mechanical

Weight	0.001	Packaging	Bulk
Orientation	N (Normal)	Termination	Crimp
Weight (g):	46.49800	Mounting Type	Wall Mount
Connector Type	Receptacle, Female Sockets	Contact Finish	Gold
Fastening Type	Bayonet Lock	Insertion Angle	:14-12
Material - Body	:Aluminium	Contact Material	:Copper
1st Contact Gender	:Socket	Number of Contacts	:12
Contact Termination	:Crimp	Number of Positions	12
Shell Size - Insert	14-12	Shell Material, Finish	Aluminum, Olive Drab Cadmium Plated
Contact Finish Thickness	50µin (1.27µm)	1st Connector Mounting Type	:Panel

Product Info

Type	MIL-C-26482 Circular	Gender	RCP
Series	:KPSE	Features	Sealing Gland, Strain Relief

Environmental

Ingress Protection

Environment Resistant

Operating Temperature

-55°C ~ 125°C

Documents & Media

PDF Document

KPT_and_KPSE_CatalogQ3_1998.pdf

Online Document

KPT/KPSE Connectors Catalog

PDF Document

58286.pdf

Similar Parts

KPSE08P14-12P

itt interconnect solutions

Conn MIL-C-26482 Circular PIN 12 POS Crimp RA Cable Mount 12 Terminal 1 Port CONN PLUG 12POS CABLE RA PIN

$446.3357

Details

KPT06J14-12P

itt interconnect solutions

Conn MIL-C-26482 Circular PIN 12 POS Solder ST Cable Mount 12 Terminal 1 Port CONN PLUG 12POS W/PIN CABLE CONNECTOR, CIRCULAR, SIZE 14, 12WAY

$443.8020

Details

KPT08E14-12P

itt interconnect solutions

Conn MIL-C-26482 Circular PIN 12 POS Solder RA Cable Mount 12 Terminal 1 Port CONN PLUG 12POS W/PIN CABLE R/A CONNECTOR, CIRCULAR, SIZE 14, 12WAY

$557.3280

Details

KPSE06E14-12P

itt interconnect solutions

Conn MIL-C-26482 Circular PIN 12 POS Crimp ST Cable Mount 12 Terminal 1 Port CONN PLUG 12POS CABLE PIN CONNECTOR, CIRCULAR, SIZE 14, 12WAY

$601.9741

Details

KPSE08E14-12P
