192990-1370
| Manufacturer | |
| Description | Conn Ringlock Circular PIN 48 POS ST Panel Mount 48 Terminal 1 Port CONN HSG RCPT WALL MNT 48POS PIN 48 Pole Female Straight Panel Mount Industrial & Automation Circular Connector with Male Contacts Panel-mount plug 48-pole Trident Ringlock Circular 48P Male 24, 192990-1370, ITT Corporation ITT Cannon 48路 面板安装 直向 连接器 插座 , 公触点 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage Rating | 250 | Number of Poles | 48 |
| Current Rating (Max) | 13 A | Voltage - Protection Level (VP) (2416) | IP 40/65 |
Mechanical
| Depth | 42.9 | Packaging | Bulk |
| Cable Exit | No | Shell Size | 24 |
| Orientation | N (Normal) | Contact Type | 48Signal |
| Mounting Type | Panel Mount | Connector Type | Receptacle for Male Contacts |
| Fastening Type | Bayonet Lock | Connector Style | with flange |
| Locking Feature | Bayonet locking | Housing Material | Polyamide (PA/Nylon) |
| Length - Overall | 34.8 | Termination Style | Crimp Connection |
| 1st Contact Gender | PIN | Number of Contacts | 48 |
| Number of Positions | 48 | Shell Size - Insert | 24-48 |
| 1st Connector Gender | Male | Shell Material, Finish | Nylon |
Product Info
| Note | Contacts Not Provided | Type | Ringlock Circular |
| Gender | RCP | Series | Trident Ringlock Circular |
| Description | Panel-mount plug | ||
Environmental
| Operating Temperature | -55...+105 °C | ||
