CA3102E14S-6PA176
| Manufacturer | |
| Description | CONN RCPT 6 POS BOX MNT W/PINS CIRCULAR, SIZE 14S, 6WAYS, PIN |
| Category |
Business
| Standard Package | 1 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :MIL-C-5015 | ||
Electrical
| Voltage Rating | 200VAC, 250VDC | ||
Mechanical
| Weight | 0.01 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Solder Cup |
| Weight (g): | 19.41400 | Mounting Type | Panel Mount, Flange |
| Connector Type | Receptacle, Male Pins | Contact Finish | Gold |
| Fastening Type | Threaded | Insertion Angle | :14S-6 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Pin | Number of Contacts | :6 |
| Contact Termination | :Crimp | Number of Positions | 6 |
| Shell Size - Insert | 14S-6 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 20µin (0.51µm) | 1st Connector Mounting Type | :Panel |
Product Info
| Gender | :Receptacle | Series | :CA-Threaded |
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
