HBS2KGB4SA011C
| Manufacturer | |
| Description | Switch Snap Action N.O./N.C. SPDT Roller Lever Solder/Screw 20A 480VAC 250VDC 0.98N Screw Mount Snap SWITCH SNAP SPDT 20A LEVER ROLLR Basic / Snap Action Switches SPDT 20A 18 OZ. OF Switch,PRECISION,HINGEDRollerLEVERACUATOR,SolderTerminalS |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 50 | Unit Pack | 1 |
| Product Category | Basic / Snap Action Switches | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Not Compliant |
Electrical
| Circuit | SPDT | Voltage Rating | 250 V |
| Switch Function | On-Mom | Differential Travel | 0.062" (1.6mm) |
| Current Rating (Max) | 20@480VAC A | Voltage - Input (Min) | 480 V |
| Switch Function/Rating | N.O./N.C. | ||
Mechanical
| Depth | 17.5 | Height | 34.85 |
| Packaging | Bulk | Pretravel | 0.312" (7.9mm) |
| Overtravel | 0.156" (3.96mm) | Contact Form | SPDT |
| Actuator Type | Lever, Roller | Mounting Type | Screw Mount |
| Release Force | 21gf | Terminal Type | Solder/Screw |
| Operating Force | 0.98 N | Contact Material | Fine Silver |
| Length - Overall | 64 | Actuator Material | N/A/N/A/Phenolic |
| Termination Style | Solder Lug | Actuator Style/Size | Roller Lever |
| Switch Actuation Level | SPDT | Material - Housing & Prism | N/A/Heat Resistant Phenolic |
Product Info
| Type | Standard | Series | HB |
| Electrical Life | 150,000 Cycles | Operating Position | 1.120" (28.45mm) |
Environmental
| Ingress Protection | IP65 - Dust Tight, Water Resistant | Operating Temperature | -55 to 150 °C |
