EPM3064ATC100-10N
| Manufacturer | |
| Description | CPLD MAX 3000A Family 1.25K Gates 64 Macro Cells 100MHz 3.3V 100-Pin TQFP IC CPLD 64MC 10NS 100TQFP EPM3064ATC100-10N, CPLD MAX 3000A EEPROM 64 Cells, 66 I/O, 4 Labs, ISP, 3 to 3.6V 100-Pin TQFP CPLD - Complex Programmable Logic Devices CPLD - MAX 3000A 64 Macro 66 IOs EPM3064ATC10010 , 最大 3000A系列 复杂可编程逻辑设备 CPLD, EEPROM存储器, 64宏单元, 66 I/O, 4逻辑块, ISP, 3 → 3.6 V, 100针 TQFP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MAX 3000A | Standard Package | 270 |
| Factory Pack Quantity | 90 | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Delay Time | 4.5 ns | Memory Type | EEPROM |
| Number of I/O | 66 | Voltage - I/O | 66 |
| Voltage Rating | 3 V | FPGA Core Cells | 64 |
| Frequency - Max | 222.2 MHz | Output Function | 是 |
| Voltage - Supply | 3.3 V | Program Memory Type | EEPROM |
| Delay Time tpd(1) Max | 10.0ns | Voltage - Supply (Min) | 3.6 V |
| Propagation Delay (Max) | 4.5 ns | Voltage Supply - Internal | 3 V ~ 3.6 V |
| Propagation Delay tpLH / tpHL (Max) | 10 | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Width | 14mm | Height | 1mm |
| Length | 14mm | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | 100 |
| Package / Case | 100-TQFP | Package Cooled | TQFP |
| Writable Memory | Yes | Length - Overall | 14 |
| Output Connector | Yes | Package Quantity | TQFP |
| Size / Dimension | 14 x 14 x 1mm | Number of Positions | 100 |
| Shell Size - Insert | 1 | Supplier Device Package | 100-TQFP (14x14) |
Product Info
| Series | MAX 3000A | Function | Y |
| Manufacturer | Intel / Altera | Programmable | 是 |
| Number of Gates | 1250 | Programmable Type | In System Programmable |
| RF Family/Standard | MAX 3000A | Number of LABs/CLBs | 4 |
| DigiKey Programmable | Yes | Number of Macrocells | 64 |
| In System Programming | Yes | Printed Circuit Board | 100 |
| Number of Inputs and Type | 66 | Number of Logic Elements/Blocks | 4 |
Environmental
| Operating Temperature | 0°C ~ 85°C | ||
