EPM1270T144I5
| Manufacturer | |
| Description | CPLD MAX II Family 980 Macro Cells 201.1MHz 0.18um Technology 2.5V/3.3V 144-Pin TQFP IC CPLD 980MC 6.2NS 144TQFP CPLD - Complex Programmable Logic Devices CPLD - MAX II 980 Macro 116 IO |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MAX II | Standard Package | Trays |
| Factory Pack Quantity | 60 | Standard Package Name | QFP |
Compliance
| RoHS | Contains lead / RoHS non-compliant | Rad Hardened | No |
Electrical
| Speed | 5 | Frequency | 1879.7 MHz |
| Delay Time | 6.2 ns | Memory Size | 8192 bit |
| Memory Type | Flash | Number of I/O | 116 |
| Voltage Rating | 2.5|3.3 V | Frequency - Max | 201.1 MHz |
| Current - Supply | 55 mA | Voltage - Supply | 2.5 V, 3.3 V |
| Program Memory Type | Flash | Delay Time tpd(1) Max | 6.2ns |
| Voltage - Supply (Min) | 2.375 V | Propagation Delay (Max) | 6.2 ns |
| Delay Time - Propagation | 10 ns | Voltage Supply - Internal | 2.5V, 3.3V |
| Propagation Delay tpLH / tpHL (Max) | 10 ns | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 20 | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 144TQFP |
| Package Cooled | TQFP | Length - Overall | 20 |
| Package Quantity | TQFP | Number of Positions | 144 |
| Shell Size - Insert | 1.4 | Supplier Device Package | 144-TQFP (20x20) |
Product Info
| Series | MAX II | DELETED | Not Compliant |
| Process | 0.18um | Manufacturer | Intel / Altera |
| Programmable | Yes | Programmable Type | In System Programmable |
| RF Family/Standard | MAX II | User Configuration | 8192 bit |
| Number of LABs/CLBs | 127 | DigiKey Programmable | Yes |
| Number of Macrocells | 980 | In System Programming | Yes |
| Printed Circuit Board | 144 | Number of Inputs and Type | 116 |
| Number of Logic Elements/Cells | 1270 | Number of Logic Elements/Blocks | 127 |
Environmental
| Operating Temperature | -40 to 100 °C | Operating Temperature - Junction | 100C |
