5M570ZT144C5N
| Manufacturer | |
| Description | CPLD MAX V Family 440 Macro Cells 118.3MHz 1.8V 144-Pin TQFP IC CPLD 440MC 9NS 144TQFP CPLD - Complex Programmable Logic Devices CPLD - MAX V 440 Macro 114 IOs |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MAX V | Other Names | 544-2720 |
| Standard Package | Trays | Factory Pack Quantity | 60 |
| Standard Package Name | QFP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Speed | 5 | Frequency | 1474.9 MHz |
| Delay Time | 9 ns | Memory Size | 8192 bit |
| Memory Type | Flash | Number of I/O | 114 |
| Voltage Rating | 1.8 V | Frequency - Max | 118.3 MHz |
| Current - Supply | 27 uA | Voltage - Supply | 1.8 V |
| Program Memory Type | Flash | Delay Time tpd(1) Max | 9.0ns |
| Voltage - Supply (Min) | 1.71 V | Propagation Delay (Max) | 9 ns |
| Voltage Supply - Internal | 1.71 V ~ 1.89 V | Propagation Delay tpLH / tpHL (Max) | 17.7|8.5 ns |
| Common Mode Transient Immunity (Min) | Commercial | ||
Mechanical
| Packaging | Tray | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 144TQFP | Package Cooled | TQFP |
| Writable Memory | Yes | Package Quantity | TQFP |
| Number of Positions | 144 | Supplier Device Package | 144-TQFP (20x20) |
Product Info
| Series | MAX V | DELETED | Compliant |
| Manufacturer | Intel / Altera | Programmable | Yes |
| Programmable Type | In System Programmable | RF Family/Standard | MAX V |
| User Configuration | 8192 bit | Number of LABs/CLBs | 57 |
| DigiKey Programmable | Yes | Number of Macrocells | 440 |
| In System Programming | Yes | Number of Inputs and Type | 114 |
| Number of Logic Elements/Cells | 570 | Number of Logic Elements/Blocks | 8 |
Environmental
| Operating Temperature | 0 to 85 °C | Operating Temperature - Junction | 85C |
