TLE6208-6G
| Manufacturer | |
| Description | Motor / Motion / Ignition Controllers & Drivers Six-fold Half-Bridge Driver 6xHaBr 0.6A 40V SO-28 SMD IC MOTOR DRIVER SPI 28DSO TLE6208-6G, Motor Driver, Hex-Half-Bridge/Double6-DriverSPISO28 Infineon 电机驱动器 IC , 用于BLDC 电机, 0.6A, 4.75 → 5.5 V |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1000 | Unit Pack | 1000 |
| Other Names | TLE6208-6GINCT | Part # Aliases | SP000305936 TLE62086GXT TLE62086GXUMA1 |
| Product Category | Motor / Motion / Ignition Controllers & Drivers | Standard Package | 1,000 |
Compliance
| RoHS | RoHS Compliant | Automotive | AEC-Q(100) |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Interface | SPI | Voltage - Max | 40V |
| Voltage - Load | 5.5 V ~ 40 V | Voltage Rating | 4.75 V |
| Current - Output | 4 mA | Voltage - Supply | 6.6 V to 40 V |
| Voltage - Supply (Min) | 5.5 V | On-State Resistance (Max) | 800mOhm |
| Current - Collector Cutoff (Max) | 1A | ||
Mechanical
| Width | 7.6mm | Height | 2.45mm |
| Length | 18.1mm | Packaging | Reel |
| Mounting Type | SMD | Mounting Style | SMD/SMT |
| Package / Case | DSO | Package Cooled | PG-DSO |
| Size / Dimension | 18.1 x 7.6 x 2.45mm | Number of Positions | 28 |
| Supplier Device Package | PG-DSO-28 | ||
Product Info
| Type | DC Motor Driver | Series | TLE6208 |
| Function | Driver - Fully Integrated, Control and Power Stage | Matchcode | TLE6208-6G |
| Applications | Automotive | Standard Leadtime | 22 weeks |
| Motor Type - AC, DC | Brushed DC | Output Configuration | Half Bridge, (6) |
Environmental
| Temperature - Test | -40°C | Operating Temperature | - 40 C to + 150 C |
| Maximum Temperature Limit | 150°C | ||
