SAF-C167CR-LM HA+
| Manufacturer | |
| Description | MCU 16-bit C166 CISC/RISC ROMLess 5V 144-Pin MQFP C166 ROMLESS MQFP-144 85°C IC MCU 16BIT FLASH 144-MQFP IC, MCU, 16BIT, FLASH, 144MQFP 16-bit Microcontrollers - MCU 16BIT ROM/ROMLESS |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 24 |
| Other Names | SAF-C167CR-LM HA+CT | Standard Package | 200 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85423190 |
| Automotive | NO | Leadfree Defin | RoHS-conform |
Electrical
| Speed | 25 MHz | RAM Size | 4 KB |
| Core Size | 16-Bit | Interface | CAN/SSC/USART |
| EEPROM Size | 0Byte | Memory Size | 0KByte |
| Memory Type | ROMLESS | Display Type | 0 |
| Number of I/O | 111 | Clock Frequency | :25MHz |
| Data Converters | A/D 16x10b | Frequency - Max | 25MHz |
| Number of DAC's | 4 | Oscillator Type | External |
| Voltage - Supply | 5 V | Digital I/O Lines | 111pins |
| Resolution (Bits) | 10Bit | Number of Channels | 0 |
| Program Memory Type | ROMLess | Number of ADCs / DACs | 16channels |
| Voltage - Input (Min) | 5.5V | Power Dissipation (Max) | 1500 mW |
| Voltage - Supply (Vcc/Vdd) | 4.5 V ~ 5.5 V | ||
Mechanical
| Weight | 0.11 | Packaging | TRAY |
| Number of Pins | :144 | Package / Case | 144MQFP |
| Material Finish | :MSL 3 - 168 hours | Number of Cores/Bus Width | 16 Bit |
Product Info
| USB | No | Matchcode | SAF-C167CR-LM HA+ |
| CAN Number | 1 | SPI Number | 1 |
| On-Chip RAM | 16-chx10-bit | Peripherals | POR, PWM, WDT |
| Connectivity | CAN, EBI/EMI, SPI, UART/USART | Core Processor | C166 |
| Number of Timers | 9 | Controller Series | :C166 |
| Standard Leadtime | 14 weeks | RF Family/Standard | C166 |
Environmental
| Temperature - Test | -40°C | Operating Temperature | -40 to 85 °C |
Documents & Media
PDF Document
