ICE3B2065P
| Manufacturer | |
| Description | Switching Controllers Off-Line SMPS Currnt Mode CTRLR 650V IC OFFLINE CTRLR SMPS OTP TO220 AC/DC Converters Off-Line SMPS Currnt Mode CTRLR 650V |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | ICE3B2065PBKSA1 | Product Category | AC/DC Converters |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Power - Max | 102W | Power (Watts) | 102W |
| Voltage Rating | 650 V | Frequency Range | 61kHz ~ 73kHz |
| Current - Output | 2 A | Duty Cycle (Max) | 77 % |
| Output Isolation | Isolated | Voltage - Supply | 8.5 V ~ 22 V |
| Number of Outputs | 1 | Voltage - Breakdown | 650V |
| Frequency - Switching | 71 kHz | Voltage - Input (Min) | 8.5 V ~ 22 V |
Mechanical
| Packaging | Tube | Mounting Style | Through Hole |
| Package / Case | TO-220-6 Formed Leads | Supplier Device Package | PG-TO220-6 |
Product Info
| Type | Current Mode PWM Controllers | Series | ICE3B2065 |
Environmental
| Operating Temperature | -40°C ~ 150°C | ||
