ESD5V3U1U-02LRH E6327
| Manufacturer | |
| Description | ESD Suppressor TVS 20KV 2-Pin TSLP TVS DIODE 5.3VWM 28VC TSLP2-7 TVS Diodes - Transient Voltage Suppressors Ult-Lw Capacitance TVS Diode DIODE, TVS ARRAY, 5.3V, TSLP-2-7 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ESD5V3U1U-02LRHE6327INCT | Part # Aliases | ESD5V3U1U02LRHE6327XTSA1 SP000394151 |
| Product Category | TVS Diodes - Transient Voltage Suppressors | Standard Package | 15,000 |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85411000 |
| ESD Protection | 20@Air Gap/20@Contact Disc kV | ||
Electrical
| Channels | 1 Channel | Capacitance | 0.6 pF |
| TVS Polarity | :Unidirectional | Voltage Rating | 5.3 V |
| Current - Surge | 3 A | Voltage - Supply | 5.3V (Max) |
| Number of Elements | 1 | Voltage - Clamping | 15 V |
| Diode Configuration | :TSLP-2-7 | Voltage - Breakdown | 6V |
| Power Line Protection | No | Voltage - Supply (Min) | 5.3 V |
| Capacitance @ Frequency | 0.4pF @ 1MHz | Unidirectional Channels | 1 |
| Current - Peak Pulse (8/20us) | :3A | Current - Reverse Leakage @ Vr | 0.1 uA |
| Current - Peak Pulse (10/1000us) | 3A (8/20µs) | ||
Mechanical
| Weight | 0.00003 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | SOD-882 | Material Finish | :MSL 1 - Unlimited |
| Size / Dimension | 0.6 mm W x 1 mm L | Termination Style | SMD/SMT |
| Number of Positions | 2 | Supplier Device Package | PG-TSLP-2 |
Product Info
| Type | TVS | Series | ESD5V3 |
| Polarity | Unidirectional | Applications | Ethernet, HDMI, Telecom |
| Port Direction | Uni-Directional | ||
Environmental
| Operating Temperature | -55 °C | ||
