ESD3V3U1U-02LS E6327
| Manufacturer | |
| Description | TVS Diodes - Transient Voltage Suppressors Ult-Lw Capacitance TVS Diode TVS DIODE 3.3VWM 28VC TSSLP2-1 DIODE, TVS, 3.3V, TSSLP-2-1 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ESD3V3U1U-02LSE6327INCT | Part # Aliases | ESD3V3U1U02LSE6327XTSA1 SP000394145 |
| Product Category | TVS Diodes - Transient Voltage Suppressors | Standard Package | 15,000 |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85412900 |
Electrical
| Channels | 1 Channel | Current - Surge | 3 A |
| Voltage - Supply | 3.3V (Max) | Voltage - Clamping | 28V (Typ) |
| Diode Configuration | :TSSLP-2-1 | Voltage - Breakdown | 5V |
| Power Line Protection | No | Voltage - Supply (Min) | 3.3 V |
| Capacitance @ Frequency | 0.4pF @ 1GHz | Power Dissipation (Max) | :0mW |
| Unidirectional Channels | 1 | Current - Peak Pulse (10/1000us) | 3A (8/20µs) |
Mechanical
| Weight | 0.000006 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | 2-XFDFN | Material Finish | :MSL 1 - Unlimited |
| Size / Dimension | 0.32 mm W x 0.62 mm L | Termination Style | SMD/SMT |
| Supplier Device Package | PG-TSSLP-2 | ||
Product Info
| Type | Zener | Series | ESD3V3 |
| Polarity | Unidirectional | Diode Type | :ESD Protection |
| Applications | HDMI | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
