BGA 622L7 E6327
| Manufacturer | |
| Description | RF Amplifier RF SILICON MMIC Amp Chipl GP 6GHz IC OP AMP WIDEBAND RF TSLP-7 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | BGA622L7E6327INDKR | Part # Aliases | BGA622L7E6327XT BGA622L7E6327XTSA1 SP000017535 |
| Product Category | RF Amplifier | Standard Package | 7,500 |
| Factory Pack Quantity | 7500 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Gain | 17.5dB | IIP3 | - 2 dBm |
| P1dB | - 20 dBm | Frequency | 500 MHz to 6 GHz |
| Output Fan | - 2 dBm | Return Loss | 7 dB |
| Noise Figure | 0.95 dB | Power Gain Typ | 17.5 dB |
| Test Frequency | 1.575 GHz | Current - Output | 5.8 mA |
| Current - Supply | 5.8 mA | Voltage - Supply | 2.75 V |
| Number of Channels | 1 Channel | Power - Average Forward | 35 mW |
| Power Dissipation (Max) | 35 mW | ||
Mechanical
| Packaging | Reel | Mounting Style | SMD/SMT |
| Package / Case | TSLP-7-1 | Supplier Device Package | TSLP-7-1 |
Product Info
| Type | Low Noise Amplifier | Series | BGA622L7 |
| RF Type | 802.15/Bluetooth, ISM, WLAN, GSM, GPS, DCS, UMTS | Manufacturer | Infineon Technologies |
Environmental
| Operating Temperature | + 150 C | ||
