1TW1-8
| Manufacturer | |
| Description | Toggle Switches SPDT 2 POSITION SOLDER TERMINATION Switch Toggle (ON) ON SPDT Round Toggle Solder 5A 125VAC 30VDC Panel Mount with Threads MICRO SWITCH™ Electromechanical Switches, MICRO SWITCH™ Toggle Switches SWITCH TOGGLE SPDT 15A 125V Switch Toggle (ON) ON SPDT Round Toggle Solder 5A 125VAC 30VDC Panel Mount with Threads Product Highlights:Qualified to MIL-S-83731Save space and weightSPDT and DPDT circuitryTemperature range: -85�F to +160�F (-65�C to +71�C)Sealed bushing versionsChoice of � in. or 15/32 in. bushingColor tab available on 15/32 in. bushingUL recognizedPotential Applications:Industrial machinery and equipmentMilitary and commercial aviationConstruction equipmentTest instrumentsAgricultural machineryProcess controlMedical instrumentation SealedOperatorControls TW Series Toggle Switch, 1 pole, 2 position, Solder terminal, Standard Lever, Military Part Number MS27716-26-1 |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 42 Days | Subcategory | Switch Toggle |
| Part # Aliases | MS27716-26-1 | Product Category | Toggle Switches |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Standard Number | Standard | Approval Agency Marking | L117: 5 A at 125 Vac |
Electrical
| Circuit | SPDT | Operation | 126794 |
| Voltage Rating | 125 V | Switch Function | On-Mom |
| Voltage - Supply | 0.1 A to 5.0 A at 0.5 Vdc to 28 Vdc|0.1 A to 5.0 A at 0.5 Vac to 115 Vac | Current Rating (Max) | 10 A |
| Voltage - Input (Min) | 125@(CSA/UL) | Switch Function/Rating | (ON) ON |
| Voltage - Continuous Operating (Max) (MCOV) | 0.1 A to 5.0 A at 0.5 Vdc to 28 Vdc|0.1 A to 5.0 A at 0.5 Vac to 115 Vac | ||
Mechanical
| Depth | 8.9 | Height | 33.4 |
| Packaging | Bulk | Termination | Solder |
| Contact Form | SPDT | Actuator Type | Lever |
| Mounting Type | Panel Mount with Threads | Terminal Type | Solder |
| Bushing Thread | 1/4-40 | Contact Finish | Silver |
| Mounting Style | Panel | Actuator Length | 10.67mm |
| Contact Material | Fine Silver | Length - Overall | 14.5 |
| Termination Style | Solder | Actuator Style/Size | Round Toggle |
| Bushing, Grommet Type | 1/4-40 | Switch Actuation Level | SPDT |
| Panel Cutout Dimensions | Circular - 6.60mm Dia | ||
Product Info
| Note | Fine silver contacts | Type | Miniature |
| Series | TW | Function | 2 position |
| Circuitry | SPDT | UNSPSC Code | 30211908 |
| Illumination | Non-Illuminated | Product Type | MICRO SWITCH⢠Toggle Switch |
| Industry Aliases | 5930012207210, MS27716-26-1 | UNSPSC Commodity | 30211908 Toggle switches |
| Equipment Part Numbers | MS27716-26-1 | ||
Environmental
| Seal Rating | Sealed | Ingress Protection | Environment Proof |
| Operating Temperature | -65°C ~ 71°C | ||
