LX60-20S
| Manufacturer | |
| Description | I/O コネクタ RCP 20 POS 0.5mm Sol RA SMD 20Termina CONN RCPT 20POS .5MM RT ANG SMD Low profile interface receptacle, 20-way I/O Connectors RCP 20 POS 0.5mm Sol RA SMD 20Termina Conn Cellular Phone Connector RCP 20 POS 0.5mm Solder RA SMD 20 Terminal 1 Port Embossed T/R Hirose LX 系列 黑色 表面安装 母 电话连接器, 焊接端接 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | H11404DKR | Product Category | I/O Connectors |
| Standard Package | 2,000 | Factory Pack Quantity | 2000 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Voltage Rating | 50 VAC | Contact Resistance | 70 mohm |
| Current Rating (Max) | 500 mA | Voltage - Supply (Min) | 50VAC |
Mechanical
| Color | Black | Depth | 6.5 mm |
| Pitch | 0.020" (0.50mm) | Height | 2 mm |
| Packaging | Tape & Reel (TR) | Termination | Solder |
| Contact Form | Center Strip Contact | Contact Type | Center Strip Contact |
| Housing Color | Black | Mounting Type | Surface Mount, Right Angle |
| Connector Type | Receptacle | Contact Finish | Gold |
| Mounting Style | SMD/SMT | Number of Rows | 1 |
| Contact Material | Copper Alloy | Housing Material | Synthetic |
| Length - Overall | 14.6 mm | Termination Rows | 焊接 |
| Termination Style | Solder | Color - Connectors | Natural |
| Number of Contacts | 20 | Number of Positions | 20 |
| Number of Positions/Bay/Row | All | ||
Product Info
| Gender | Female | Series | LX |
| DELETED | Compliant | Features | Board Guide |
| Main Purpose | Board Guide | Number of Ports | 1 |
| Output Configuration | Surface Mount, Right Angle | Number of Positions Loaded | All |
Environmental
| Operating Temperature | +70°C | ||
