HR10A-7P-4PC(73)

Manufacturer	Hirose Electric Co., Ltd.
Description	Circular Push Pull Connectors 4P PLUG SHELL SZ 7 MALE CRIMP CONN HR10A PLUG 4POS MALE Connector,circular,plug,male,size 7,4w Hirose HR10 系列 4路电缆安装直向连接器 , 公触点, 推挽式接合
Category	Connector SolutionsCircular ConnectorsIndustrial Circular Connectors

对参数有疑问？问 AI 助手

Business

Product Category	Circular Push Pull Connectors	Standard Package	20
Factory Pack Quantity	1

Compliance

RoHS

Compliant

Electrical

Voltage Rating	150 V ac	Connector Impedance	微型
Current Rating (Max)	2A	Connector - Voltage Input	Micro

Mechanical

Outline	7mm	Packaging	Bulk
Shell Size	7mm	Wire Gauge	30
Orientation	Keyed	Shell Style	Plug
Termination	Crimp	Contact Size	1.0mm
Contact Type	Crimp	Mounting Type	Free Hanging (In-Line)
Shell Plating	Nickel	Connector Type	Plug for Male Contacts
Contact Finish	Silver	Fastening Type	Push-Pull
Mounting Style	Cable	Shell Material	Metal
Connector Usage	Push-Pull	Contact Material	Brass, Bronze
Housing Material	Brass, Zinc Alloy	Termination Rows	压接
Termination Style	Crimp	1st Contact Gender	Male
Number of Contacts	4	Number of Positions	4
Shell Size - Insert	7	Shell Material, Finish	Brass and Zinc, Nickel Plated

Product Info

Note	Contacts Not Provided	Gender	Male
Series	HR10A	Product Type	Connectors

Environmental

Operating Temperature

+85°C

Documents & Media

PDF Document

HR10 Series

PDF Document

e11000216.pdf
