点击放大查看
09560008175
| Manufacturer | |
| Description | D-Sub Contacts MALE CRIMP CONTACT S4 PLATING DSUB HD MA CONTACT 24-26 AWG S4 DSUB HD crimp contact male 24-26 AWG Harting 公 压接 D-sub 连接器触点, 镀金 触点, 26 → 24 AWG |
| Category |
Business
| Part # Aliases | 000 09 09-56-000-8175 56 8175 | Product Category | D-Sub Contacts |
| Standard Package | 1 | Factory Pack Quantity | 500 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Contact Resistance | 20mΩ | Current Rating (Max) | 2A |
Mechanical
| Length | 14mm | Packaging | Bulk |
| Wire Gauge | 24-26 AWG | Termination | Crimp |
| Contact Form | Stamped | Contact Type | Male Pin |
| Connector Type | 公插 | Contact Finish | Gold |
| Contact Material | Copper Alloy | Termination Rows | 压接 |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Contact Termination | Crimp | Contact Finish Thickness | 30µin (0.76µm) |
| Wire Gauge or Range - mm2 | 26 → 24 AWG | ||
Product Info
| Type | Signal | Gender | Male |
| Series | 956 | Features | High Density (HD), Insulation Support |
Similar Parts
09564005601
HARTING
D-Sub High Density Connectors 62P MALE CRIMP THRU HOLE DSUB HD MA CRIMP SHELL 62P HD Crimp connector for 62-pin M HighDensityCrimpConnector(DSubHDMaleCrimpShell)62position Harting 62路 2.41mm节距 直 压接式 D-sub 连接器, 插头
09562005601
