F3345-160
| Manufacturer | |
| Description | SMD Crystal Oscillator 16MHz 5V 50pF 4-Pin SMD T/R F3345-160, Crystal Oscillator, 16MHz, ±100ppm HCMOS, TTL 50pF, 4-Pin SMD, 7.5 x 5.2 x 1.5mm Standard Clock Oscillators SMD 5.0V 16MHz F3345-160 Fox Electronics 16 MHz 晶体振荡器, ±100ppm, HCMOS，TTL输出, 50pF, 4针 表面安装器件封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | XO | Product Category | Standard Clock Oscillators |
| Standard Package | Bulk | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Symmetry | 55 % | Frequency | 1600 MHz |
| Output Signal | HCMOS|TTL | Voltage Rating | 4.5 V |
| Duty Cycle (Max) | 55 % | Load Capacitance | 50 pF |
| Voltage - Supply | 5 V | Frequency Stability | ±100 ppm |
| Frequency - Output 1 | 16 MHz | Frequency - Operating | 16 MHz |
| Voltage - Supply (Min) | 5.5 V | Max Propagation Delay @ V, Max CL | 55% |
Mechanical
| Width | 5.2mm | Height | 1.5mm |
| Length | 7.5mm | Packaging | Reel |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | 4 | Package / Case | 4SMD |
| Package Cooled | SMD | Package Quantity | SMT |
| Size / Dimension | 7.5 x 5.2 x 1.5mm | Termination Style | SMD/SMT |
| Number of Positions | 4 | ||
Product Info
| Type | Crystal Oscillator | Series | F3345 |
Environmental
| Operating Temperature | +70 °C | ||
Documents & Media
PDF Document
