FLUKE-233

Manufacturer	Fluke Corporation
Description	Digital Multimeters REMOTE DISPLAY TRMS MULTIMETER MULTIMETER REMOTE TRMS DIGITAL RSCAL(6698313) TRMS Wireless Display Digital Multimeter,TRMS Wireless Display UKAS(6698313) TRMS Wireless Display MULTIMETER, DIGITAL, HAND HELD, 6000 Multimeter,TrueRMS,RemoteDisplay Digital multimeter; LCD (6000); V DC:0,1m÷600m/6/60/600/1000V True-RMS Remote Display Multimeter for Accurate Measurements on Non-linear Signals Multimeter digital FLUKE 233 TRMS AC 6000 digits 1000 VAC 1000 VDC 10 ADC, FLUKE 233, Fluke
Category	Testing, Inspection, and Prototyping SolutionsElectrical & Electronic TestAnalogue Multimeters

对参数有疑问？问 AI 助手

Business

Product	Multimeters	Part # Aliases	3463576
Product Category	Digital Multimeters	Standard Package	1

Compliance

RoHS	RoHS Compliant By Exemption	SVHC	:No SVHC (20-Jun-2013)
Standards	CATIV600V,CATIII1000V	Tariff No	90303100

Electrical

Ranging	Auto	Accuracy	0.25 % to 1.5 %
Response	True RMS	Frequency	50 kHz
Resistance	40MΩ	Capacitance	1000nFto9999μF
Display Type	LCD	Power - Input	3 batteries 1,5V LR6 (AA), 2 batteries 1.5V LR6 (AA) (display module)
Response Time	:True RMS	Voltage Range	1 kV
Frequency Range	0.1Hzto50.0kHz	Current - Output	10A
Capacitance Range	10000 uF	Capacitance - Input	±(1,9% + 2 digits)
Diode Configuration	1,2mA, 2,7V	Frequency Tolerance	±(0,1% + 2 digits)
Resistance Tolerance	:0.1ohm to 40Mohm	Voltage - Input (Min)	:100µA to 10A
Voltage - Supply (Min)	:100µV to 1kV	Available Frequency Range	:0.1Hz to 50kHz
Current - Output 1 (Range)	0.1mAto10.0A	Voltage - Input Offset (Max)	±(0,25% + 2 digits)
Accuracy - Voltmeter; Ammeter	Yes	Input Range (Current, Voltage)	0,1m...600m/6/60/600/1000V

Mechanical

Depth	:5.3cm	Width	:9.3cm
Length	:19.3cm	Weight	1.332 lbs
Material	RubberOvermold	Size / Dimension	2.08×2.08×7.6(5.3×5.3×19.3)In.(cm.)
Dimensions - Overall	93 x 53 x 193mm

Product Info

Type	Digital (DMM)	Style	Handheld
Series	:Fluke 233	Features	Backlight, Hold, Min/Max/Ave, Sleep
Function	Voltage, Current, Resistance, Capacitance, Temperature, Frequency	Includes	Battery, Manual, Test Leads, Temperature Probe, Clips
Warranty	3Years	Batteries	AAAlkaline—3forMainBody,2forDisplay
Plug Type	:-	Meter Type	digital multimeter
Display Count	6000	Display Style	6000Counts,LCD
Battery Series	400Hours	Display Digits	3.75
Number of Units	1	Functions, Extra	Continuity, Diode Test
Digits or Characters	:-	Other Specifications	:100µV to 1kV

Environmental

Operating Range	:-40°C to +400°C	Lifetime @ Temp.	:400h
Temperature - Test	-40...400°C	Operating Temperature	–40to+400°C
Temperature Coefficient	±(1% + 10 digits)
