LM20-SO
| Manufacturer | |
| Description | Bluetooth / 802.15.1 Modules Bluetooth 2.0 trnsvr SO package 3.3V MODULE TXRX BLUETOOTH 2 18SMD |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Bluetooth / 802.15.1 Modules | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Data Rate | 570 Kbps | Frequency | 2.4GHz |
| Interface | RS-232 | Modulation | PCM |
| Output Power | 100 mW | Data Interface | PCB, Surface Mount |
| Power - Output | 20dBm (100mW) | Voltage - Supply | 3.3 V |
| Current - Receiving | 33.4mA | Current - Transmitting | 22mA |
| Frequency Bands (Low / High) | 2.4 GHz | ||
Mechanical
| Packaging | Tube | Mounting Style | SMD/SMT |
| Package / Case | 18-SMD | Size / Dimension | 35.3 mm x 14 mm x 2.3 mm |
| Antenna Connector | Integral | ||
Product Info
| Class | 1 | Applications | PDA's, Portable Audio/Video, Smartphones |
| Modulation or Protocol | Bluetooth v2.0, Class 1 | ||
Environmental
| Operating Temperature | + 85 C | ||
