LM20-DIL
| Manufacturer | |
| Description | Bluetooth / 802.15.1 Modules Bluetooth 2.0 trnsvr DIL package 3.3V-5V MODULE TXRX BLUETOOTH 2 18DIP |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Bluetooth / 802.15.1 Modules | Standard Package | 1 |
Compliance
| RoHS | No | ||
Electrical
| Data Rate | 570 Kbps | Frequency | 2.4GHz |
| Interface | RS-232 | Modulation | PCM |
| Output Power | 100 mW | Data Interface | PCB, Through Hole |
| Power - Output | 20dBm (100mW) | Voltage - Supply | 3.3 V to 5 V |
| Current - Receiving | 33.4mA | Current - Transmitting | 22mA |
| Frequency Bands (Low / High) | 2.4 GHz | ||
Mechanical
| Packaging | Tube | Mounting Style | Through Hole |
| Package / Case | 18-DIP Module | Size / Dimension | 37.5 mm x 19.5 mm x 6.5 mm |
| Antenna Connector | Integral | ||
Product Info
| Class | 1 | Applications | PDA's, Portable Audio/Video, Smartphones |
| Modulation or Protocol | Bluetooth v2.0, Class 1 | ||
Environmental
| Operating Temperature | + 85 C | ||
