XR8052AMP8
| Manufacturer | |
| Description | IC OPAMP DUAL VFB 62MHZ RR 8MSOP EXAR 双 运算放大器, 65MHz 轨至轨, 0 → 14 V, 8针 MSOP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Electrical
| Frequency | 16nV/√Hz | Slew Rate | 190 V/µs |
| Output Type | Rail-to-Rail | Power - Input | 双，单 |
| Conversion Type | 190V/µs | Current - Output | 2.6mA |
| Voltage - Supply | 2.7 V ~ 12.6 V, ±1.35 V ~ 6.3 V | Number of Elements | 2 |
| Current - Input Bias | 1.3µA | Typical Voltage Gain | 92 dB |
| Frequency - Operating | 5 MHz | Voltage - Input (Min) | 500µV |
| Gain Bandwidth Product | 175MHz | Current - Output / Channel | 100mA |
| Voltage - Supply, Dual (V+/-) | ±5V | ||
Mechanical
| Width | 3mm | Height | 0.86mm |
| Length | 2.95mm | Packaging | Tube |
| Mounting Type | Surface Mount | -3db Bandwidth | 65MHz |
| Number of Pins | 8 | Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Package Quantity | MSOP | Size / Dimension | 2.95 x 3 x 0.86mm |
| Supplier Device Package | 8-MSOP | ||
Product Info
| Function | Y | Amplifier Type | Voltage Feedback |
| Number of Circuits | 2 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
